What's Included:
- 1 - LED 7 Function 4" Box Tail Light Right Side With Pig Tail
- 1 - LED 7 Function 4" Box Tail Light Left Side With Pig Tail
- 2 - LED Amber P2/PC Side marker Amber Lens With 6" Pigtail
- 1 - LED Sealed ID Light Bar Red Low Profile ID Bar Red Lens (80")
- 1 - LED DOT Rated License Plate Light
- 1 - Plastic License Plate Bracket
- 1 - 25 Foot 4 Flat Wishbone Wiring Harness
- 1 - 7 Way Plug
- 18FT - 6 Way Cable - 14 Gauge
- 4 - Tail Light Mounting Bolts and Nuts
Features:
- Traditional style fits many applications
- TecSeal Urethane Potting - Guaranteed Circuit Board Protection
- IP68 Rated - Dust and water proof with hermetic seal
- Durable impact resistant lens
- Meets all FMVSS 108 requirements for narrow and wide vehicles
- Reliable performance over 100,000 hours
- Fits standard mounting as a direct replacement
- Tail Lights:
- Functions include
- Stop
- Turn
- Tail
- Clearance
- Side marker
- Side Reflector
- Rear Reflector
- License Plate Light (Left)
- WIRE COLORS: White Ground, Brown Low/License Plate (left), Green (right) High, Yellow (left) High
- Side marker Lights:
- Surface mounted PC/P2 rated marker light
- Automotive exterior lighting grade polycarbonate
- Wire Colors: White Ground, Red/Amber Positive
- Light Bar:
- Can be mounted horizontal, vertical, or at any angle
- Wire colors: White Ground, Black Positive
- License Plate Light:
- Life performance over 50,000 hours
- Easily mounts using just two screws
- Wire colors: Bidirectional positive and ground
- Wire Harness
- Ergonomic plug, provides grip for easier plug and unplugging from your vehicle
- The 4-Pin design is an industry standard for taillights, brake lights, and turn lights
- Bonded wires and molded rubber protect by SAE J-1128 standards
